Incl. VAT

Engine Size: 30.1cm³
Power Output: 1.2kW
Bar Length: 12″ or 14″
Weight: 4.1kg
Entry-level model for cutting firewood. Now with the environmentally-friendly and economical STIHL 2-MIX engine, easy to operate with combi-level, automatic STIHL Ematic chain lubrication system for optimum lubrication of the chain.


1) Without fuel, without bar and chain
2) K-factor according to DIR 2006/42/EC = 2.5 dB (A)
3) K-factor according to DIR 2006/42/EC = 2m / s ²

    Standard features

  • Anti-vibration system

    Intense vibration at the handles of power tools can lead to long-term effects on blood vessels in the hands and arms. STIHL has therefore developed an effective anti-vibration system whereby the oscillations from the machine’s engine are dampened which significantly reduces vibrations at the handles.

  • Compensator

    This controller in the carburettor prevents the fuel-air mixture getting richer as the air filter becomes clogged. The correct quantity of fuel is delivered to the carburettor depending on the quantity of air passing through the air filter. This keeps the fuel/air ratio in the combustion mixture constant and hence also the engine power. The filter doesn’t need to be cleaned until an appreciable drop in power occurs.

  • Single-lever master control

    All important functions such as start, choke, throttle and stop are operated via a single lever.

  • Ematic chain lubrication system

    The Ematic chain lubrication system ensures pinpoint lubrication of the saw chain links and guide bar rails. When used with STIHL OILOMATIC saw chain, it will provide maximum lubrication, longer wear and less oil consumption than conventional methods of chain lubrication. The Ematic system can reduce bar oil consumption by up to 50%.

  • Displacement cm³: 30.1
  • Power output kW/bhp: 1.2/1.6
  • Power-to-weight ratio kg/kW: 3.4
  • Weight kg1): 4.1
  • Sound pressure level dB(A)2): 100
  • Sound power level dB(A)2): 111
  • Vibration values left/right m/s²3): 5.2/5.5
  • Chain brake: QuickStop
  • STIHL Oilomatic saw chain pitch/type: 3/8″ P PMM3
  • Oil tank volume cm3): 145
  • Tank volume l: 0.25
