JEFFERSON 60 CED DIRECT OIL HEATER

530.00

Incl. VAT


This infrared oil heater delivers heat fast and exactly to the place where it is required without any air movement. It’s suitable for dust-free drying walls or paints, defrosting machinery or pipe lines, heating and working areas

JEFFERSON 60 CED DIRECT OIL HEATER

Model Description: –

  • Thermally protected motor
  • Electronic flame control with photocell
  • Possible connection to an optional room thermostat
  • Stainless steel combustion chamber
  • Oil tank included
  • Durable external powder coating
  • Strong and long lasting construction
  • Housing remains cool to the touch
  • Easy to move
  • High air displacement
  • Easy maintenance
  • Two oil filters: oil tank filter and suction filter

Main features:
Advantages

  • High air displacement
  • Integral fuel gauge
  • Thermal protection for motor
  • Error indicator light
  • Electronic flame control
  • Durable steel construction
  • Hard wearing, solid rubber wheels
  • Fuel Type: Diesel/Kerosene/Paraffin
  • Powder coated housing remains cool to the touch
  • Adjustable thermostat to control heat output
  • Stainless steel combustion chamber

Accessories

  • Room thermostat TH 5 with cable
    3 m – 4150.105, 10 m – 4150.112
    range: 0-36°C, accuracy: ± 1,5°C
  • Digital thermostat THD with
    5 m cable – 4150.106
  • Trolley – 4201.159
  • Manometer – 4201.187

How it works
Radiant heating – air flow
Remember
Ventilation of the room is necessary to prevent a deficiency in oxygen supply.

This infrared oil heater delivers heat fast and exactly to the place where it is required without any air movement. It’s suitable for dust-free drying walls or paints, defrosting machinery or pipe lines, heating and working areas

Suitable for;

Garages, Workshops, Construction Sites, Sheds, Warehouses, Events & Marquees, Building Locations, Storage Areas & Milking Parlour’s

Product Details: –

  • Power: 20 kW
  • Output: 70.000 BTU/hour
  • Output: 17.500 Kcal/hour
  • Air Displacement: 400 m³/h
  • Fuel Consumption: 1.7 kg/hour
  • Tank Capacity: 19 Litres
  • Dimensions (l x w x h): 810 x 350 x 450 mm
  • Power Supply: 220-240/50 V/Hz
  • Rated Current: 1,0 A
  • Thermostat Control: Optional
  • Net/ Gross Weight: 17/19 kg
  • Pallet: 15 pcs
